TXR X-ray System CTM - Elevating Table and Tilting Wall Stand with Auto-Positioning

Regular price $114,400.00 Sale

Product Details

CTM - Elevating Table and Wall Stand with Auto-Positioning

NETAP

Elevating Table with Auto-Positioning Capabilities:

  • 660 lb (300 kg) weight capaci ty. 86.5" (220 cm) x 34" (86.8 cm) table top
  • Vertical travel of 21.6" (55cm) to 35.4" (90cm)
  • Adjustable automatic stops at 3 positions
  • Collision protection
  • Laminate Table Top (Carbon Fiber Optional)
  • Table top movement:

               Longitudinal 43" (+24" / -19.5")
               Transverse 10" (±5")
               Vertical 14"

  • Longitudinal Bucky travel 24"
  • Reciprocating Bucky with Manual Cassette Tray
  • 103 line, 10:1 ratio, aluminum grid

CSAP

Nova CTM - with Auto-Positioning to Table and/or Wall Stand

  • Aluminum construction, reduces weigh
  • 360° vertical and horizontal rotation
  • 15' longitudinal rails, provides 139.57" (354.5cm) longitudinal travel
  • 10' bridge, provides 74.8" (190.1cm) transverse travel
  • Ceiling Rail for Cable draping of the high voltage cables
  • Maximum transverse travel 92.5" (235.2 cm)
  • Maximum longitudinal travel 187.5" (476.5 cm)
  • Vertical travel 63" (160 cm)
  • Digital display of tube for SID and tube angulation
  • Intuitive color-coded lock releases
  • Electromagnetic brakes
  • Electromagnetic angulations and rotation locks remain ON even when system is OFF. The electromagnetic longitudinal and transverse locks remain ON only when system is ON.
  • Tube rotation around vertical column ±135° with detents every 45°
  • Tube rotation around column horizontal axis ±180° with detents every 45°
  • Plug-in electrical assemblies reduce time associated with installation, calibration & maintenance
  • Trunnion Tube Mount and Cover for X-Ray Tube
  • Automatic alignment of tube with table and/or wall stand

NBSTILTMAP

Tilting Wall Stand, floor-to-wall mounted with Auto-Positioning Capabilities

  • Motorized Vertical travel 16" (41cm) to 75" (191cm), Electromagnetic locks
  • Reciprocating Bucky with Manual Cassette Tray, 103 line, 10:1 ratio aluminum grid
  • +90° / -20° tilt angulation

    E7242X

    X-Ray Tube - - 200,000 heat unit, 0.6-1.5mm focal spots, 270° horn angle

    SCOL-225ETBLL

    Collimator - Certified manual collimator with LED, laser light, swivel mount

    HT20M/FC20M

    Cables - pair - 65' long (20 meters) with vinyl cable wrap.
