AMRAD® Medical DR Series Generator

Regular price $34,927.00 Sale

Product Details

AMRAD® Medical 800DR High-Frequency Generator

  • Up to 400 kHz, 80 kW High Frequency (HF) generator
  • Anatomical Programming
  • Twenty-one (21) mA stations: 10-1000
  • kVp range: 40-150 in 1 kV steps
  • mAs range: 0.1-1000 mAs
  • Pedestal Mount and Handswitch
  • Operates from 3-phase, 400-480V electric service
  • Dual Speed Starter INCLUDED

AMRAD® Medical 650DR High-Frequency Generator

  • Up to 400 kHz, 65 kW High Frequency (HF) generator
  • Anatomical Programming
  • Twenty (20) mA stations: 10-800
  • kVp range: 40-150 in 1 kV steps
  • MAs range: 0.1-800 mAs
  • Pedestal Mount and Handswitch
  • Operates from 3-phase, 208-230V (External transformer required for 208-230V,
  • additional charges apply. DSS is not available for incoming power configuration) or 400-480V electric service
  • Dual Speed Starter INCLUDED

AMRAD® Medical 500DR High-Frequency Generator

  • Up to 400 kHz, 50 kW High Frequency (HF) generator
  • Anatomical Programming
  • Nineteen (19) mA stations: 10-630
  • kVp range: 40-150 in 1 kV steps
  • MAs range: 0.1-630 mAs
  • Pedestal Mount and Handswitch
  • Operates from 3-phase, 208-230V, or 400-480V electric service

AMRAD® Medical 400DR High-Frequency Generator

  • Up to 400 kHz, 40 kW High Frequency (HF) generator
  • Anatomical Programming
  • kVp range: 40-125
  • MA stations: 10-500
  • MAs range: 0.1-500 mA
  • Pedestal Mount and Handswitch
  • Operates from 1-phase, 208-230V or 3-phase, 208-230 or 400-480VAC electric service

Specifications of the AMRAD® Medical DR Series

  • Technique selections:
  • 1) kVp / mAs
  • 2) kVp / mA / Time
  • 3) Anatomical Programming / Patient size
  • 4) Anatomical Programming / AEC (optional)
  • 5) kVp with AEC (optional)
  • LCD display of all technique factors ( mA, kVp, mAs)
  • LCD display of Bucky, film speed, and focal spots
  • Tracks 3 film/screen combinations in AEC mode
  • Self-calibrating generator
  • X-ray tube overload protection
  • Self-diagnostics
  • 50 ft. console interconnect cable
  • TÜV SÜD, CE

Footnotes:

  • A Generators purchased as a loose component has a 1-year Parts Warranty 04/22 49 of 82
